The Connect-Tools

Flexible Tools

RF::RobotConnect

RF::ABBConnect | RF::FANUCConnect | RF::KUKAConnect

RF::RobotConnect is the connection to virtual or real robot controllers of the RF::Suite. RF::RobotConnect makes it easy to connect to real or virtual robot controllers.

This enables the integration of virtual robot controllers into the virtual commissioning. RF::RobotConnect can also be used to read signals from real robot controllers. This function is used for use in the virtual shadow.

RF::RobotConnect provides an interface to ABB, FANUC and KUKA robot controllers. The interface to the virtual system is ensured via a memory image (ShM or WinMod interface). This enables easy communication with the various robot controllers.

RF::Suite
Connection to robot controllers of ABB robots

RF::ABBConnect

RF::Suite

RF::ABBConnect is the connection to virtual or real robot controllers of ABB robots.

RF::ABBConnect makes it easy to connect to real or virtual robot controllers. This enables the integration of virtual robot controllers into the virtual commissioning.

RF::ABBConnect can also be used to read signals from real robot controllers. This function is used for use in the virtual shadow. RF::ABBConnect ensures that signals can be only read but not written.

Connection to robot controllers of FANUC robots

RF::FANUCConnect

RF::Suite

RF::FANUCConnect is the connection to virtual or real robot controllers of FANUC robots.

RF::FANUCConnect makes it easy to connect to real or virtual robot controllers. This enables the integration of virtual robot controllers into the virtual commissioning.

RF::FANUCConnect can also be used to read signals from real robot controllers. This function is used for use in the virtual shadow. RF::FANUCConnect ensures that signals can be only read but not written.

Connection to robot controllers from KUKA robots

RF::KUKAConnect

RF::Suite

RF::KUKAConnect is the connection to virtual or real robot controllers of KUKA robots.

RF::KUKAConnect makes it easy to connect to real or virtual robot controllers. This enables the integration of virtual robot controllers into the virtual commissioning.

RF::KUKAConnect can also be used to read signals from real robot controllers. This function is used for use in the virtual shadow. RF::KUKAConnect ensures that signals can be only read but not written.

RF::PLCConnect

RF::AllenBradleyConnect | RF::FSConnect | RF::SiemensRead | RF::SimUnitConnect | RF::PLCSimConnect

RF::PLCConnect is the connection to virtual or real PLC controllers of RF::Suite.

RF::PLCConnect makes it easy to connect to real or virtual PLCs. This enables the integration of real or virtual PLC controls into the virtual commissioning.

RF::PLCConnect can also be used to read signals from real PLC controllers. This function is used for use in the virtual shadow.

RF::PLCConnect provides an interface to Allen-Bradley PLCs, Phoenix PLCs, Siemens PLCs, Siemens Soft-PLC.

RF::Suite
Connection to Allen-Bradley PLCs

RF::AllenBradleyConnect

RF::Suite

RF::AllenBradleyConnect is the connection to real Allen-Bradley PLCs of RF::Suite.

With RF:: AllenBradleyConnect you can easily connect to real Allen-Bradley PLCs. This enables the integration of real PLC into the virtual commissioning.

Connecting the RF::FSBox

RF::FSConnect

RF::Suite

RF::FSConnect is the connection to the RF::FSBox of RF::Suite.

RF::FSConnect makes it easy to connect to the RF::FSBox. This enables the integration of real PLC into the virtual commissioning.

RF::FSConnect can also be used to establish communication with the virtual PLC PLCSim Advanced.

The connection to the virtual PLC controller PLCSim

RF::PLCSimConnect

RF::Suite

RF::PLCSimConnect is the connection of the RF::Suite to the virtual PLC control PLCSim.

Using RF::PLCSimConnect a connection to the virtual PLC control can be easily established. This enables the integration of the virtual PLC controller PLCSim into the virtual commissioning.

The connection to the simulation box "SimUnit" from Siemens

RF::SimUnitConnect

RF::Suite

RF::SimUnitConnect is the connection of the RF::Suite to the simulation box "SimUnit" from Siemens.

Using RF::SimUnitConnect a connection to the "SimUnit" can easily be established. This enables the integration of real PLC controls into the virtual commissioning.

Connection to real PLC from Siemens

RF::SiemensRead

RF::Suite

RF::SiemensRead is the connection of the RF::Suite to real PLC controls from Siemens.

RF::SiemensRead can be used to easily establish a connection to the real PLC. This enables the integration of real PLC in the virtual shadow. RF::SiemensRead ensures that signals can be only read but not written.

RF::DS

RF::DS is the coupling tool for ShM memory images of RF::Suite.

Using RF::DS memory images can be easily coupled between different systems.

RF::DSServer is started on one of the systems which manages the memory images. On other systems memory images can then be easily accessed via RF::DSClient.

During virtual commissioning all applications can be easily distributed to several computers connected in a network.

RF::Suite
